GAC GA6 2021-2023 Fuse Layout
In this article we look at the second generation GAC GA8, produced from 2021 to 2023. Here you will find the fuse box diagrams of the GAC GA8 2021, 2022 and 2023, get information on the location of the fuse boxes in the car and learn about the assignment of each fuse (fuse layout) and relay. Passenger Compartment Fuse Box Fuse Box Location Open the cab lower protective plate storage box in the arrowed direction and pull it out. Fuse Box Diagram Assignment of the fuses in the dashboard № Amps Function IF01 Shorting link — IF02 7.5A A/C control
